SFLO SD E



Applications

  • Ideal for water supply in off-grid and remote locations where traditional power sources are unavailable.

  • Suitable for irrigation systems in fields and farms, enhancing water access efficiency.

  • Provides a reliable water source for rural communities, promoting sustainable development.

  • Useful for emergency situations, offering a solar-powered solution for temporary water supply needs.

  • Adaptable to varying environmental conditions, offering flexibility in deployment for different climates and terrains.

Operating Conditions

  • Non-corrosive water; the volume ratio al sand content no more than 3%; particle size less than Imm
  • Max medium temperature up to +40°C; PH value remains 5-10
  • Work close to the rated head and must be immersed in water.
  • Pump efficiency is 85% raises 20% than the traditional AC Pump
  • New floating style impeller avoids axial pressure to the motor
  • Compact structure high lift, noiseless
  • Complete electric protecting controller against over and under voltage overflow, overload, dry running
  • Automatic recovery
  • Easy to Install

Pump Specifications

Model W Current
(A)
Rated
motor
voltage
Solar Array Voltage (V) controller Max
Voltage(V)
Input
Voltage(V)
Max Input Voltage (V) Peak Voltage (V) Rated
Motor
Voltage
Open Circuit Voltage (VOC) PV Modules (W) DN (") Dimenison(mm) Weight (kg)
Length (mm) Width (mm)
SFLO SD E400 400 8.3 48v 50V-70V 96 24V-72V ≥50 48 <100 2 x 335w panel 1.25" 76 1020 17
SFLO SD E600 600 12.5 48v 50V-70V 96 24V-72V ≥60 48 <100 2 x 335w panel 1.25" 102 658 34
SFLO SD E800 800 16.5 48v 50V-70V 96 24V-72V ≥60 48 <200 2 x 335w panel 1.25" 100 860 21
SFLO SDE1000 E1000 1000 13.8 72V 80V-110V 150 50V-108V ≥112 72 <350 2 x 475w panel 2" 125 764 38

Product Video

Datasheet/Downloads SFLO SD E Datasheet
