SSWP



Typical Applications

  • For water supply from wells or reservoirs
  • For domestic use, for civil and industrial application
  • For Garden use and irrigation

Operating Conditions

  • Maximum fluid temperature up to +35°
  • Maximum sand content:0.15%
  • Minimum well diameter:130mm

Motor and Pump

  • Renewable motor
  • Single-phase:220V/50Hz
  • Three-Phase:380V/50Hz
  • Equip with start control box or digital auto-control box
  • It's available to equip with floating switch
  • Curve tolerance according to ISO 9906101
  • Enclosure Class: X8
  • Insulation Class: B
  • Voltage: 1x240V
  • Speed: 2900rpm

Technical Data

Model
Supply
 Motor P2 Current at 50 Hz (A)
Stages
Max. head (m)
Max. flow (m³/h)
Outlet
 Dimensions (mm)
Weight (kg)
kW HP Operating In Starting Ist Ø D P M T
SSWP 600 220-240 V / 380-415 V 0.55 0.75 4.5 / 1.7 20 / 8 3 35 6 1¼" — — — — —
SSWP 900 220-240 V / 380-415 V 0.92 1.25 7 / 2.6 31 / 12 5 58 6 1¼" — — — — —
SSWP 1100 220-240 V / 380-415 V 1.1 1.5 8.2 / 3 37 / 14 6 70 6 1¼" — — — — —
SSWP 1300 220-240 V / 380-415 V 1.3 1.75 9.5 / 3.5 43 / 16 7 81 6 1¼" — — — — —
SSWP 1500 220-240 V / 380-415 V 1.5 2 10.8 / 4 49 / 18 8 93 6 1¼" — — — — —


Product Video

Datasheet/Downloads SSWP Datasheet
