| PARAMETER |
SML-2000-12 |
SML-3200-24 |
| GENERAL |
| Rated Power |
2000 VA / 1600 W |
|
| Battery System Voltage |
12 VDC |
24 VDC |
| AC INPUT |
| Nominal Input Voltage |
230 VAC |
230 VAC |
| Selectable Input Range — Computer Loads |
170 – 280 VAC |
170 – 280 VAC |
| Selectable Input Range — Appliance Loads |
90 – 280 VAC |
90 – 280 VAC |
| Input Frequency Range |
50 Hz / 60 Hz (auto sensing) |
50 Hz / 60 Hz (auto sensing)
|
| AC OUTPUT |
| Output Voltage Regulation |
230 VAC ± 5 % |
230 VAC ± 5 % |
| Output Waveform |
Pure sine wave |
Pure sine wave |
| Surge Power (20 ms) |
4000 VA |
6400 VA |
| Peak Efficiency — PV to Inverter |
98 % |
98 % |
| Peak Efficiency — Battery to Inverter |
94 % |
94 % |
| Transfer Time — Computer Loads |
10 ms |
10 ms |
| Transfer Time — Appliance Loads |
20 ms |
20 ms |
| BATTERY & CHARGER |
| Nominal Battery Voltage |
12 VDC |
24 VDC |
| Float Charge Voltage |
13.5 VDC |
27.0 VDC |
| Overcharge Protection |
16.0 VDC |
33.0 VDC |
| Maximum AC Charging Current |
60 A |
60 A |
| SOLAR CHARGER (MPPT) |
| Solar Charger Type |
MPPT |
MPPT |
| Maximum PV Array Power |
3000 W |
3000 W |
| MPPT Operating Voltage Range |
30 – 400 VDC |
30 – 400 VDC |
| Maximum PV Open-Circuit Voltage (Voc) |
400 VDC |
400 VDC |
| Maximum PV Input Current |
1 × 13 A (single tracker) |
1 × 13 A (single tracker)
|
| Maximum Solar Charging Current |
80 A |
80 A |
| Maximum Solar + AC Charging Current |
80 A |
80 A |
| MECHANICAL |
| Dimensions (H × W × D) |
357 × 273 × 95 mm |
|
| Carton Dimensions (H × W × D) |
435 × 335 × 165 mm |
|
| Net Weight |
4.6 kg |
4.8 kg |
| Gross Weight |
5.6 kg |
5.8 kg |
| Mounting |
Wall-mounted |
Wall-mounted |
| BATTERY BANK CONFIGURATION — BATTERIES ONLY, NOT SOLAR PANELS¹ |
| Battery Modules in Series |
Not permitted — parallel connection only |
Not permitted — parallel connection only
|
| Compatible SATTE Lithium Battery |
SH-UIB-P12100 / P12150 / P12200 (12.8 V) |
S200Ah, 24 V 200 Ah (4.8 kWh)
|
| Min. Battery Modules — 12.8 V (SH-UIB series) |
1 |
— |
| Min. Battery Modules — S200Ah, 24 V 200 Ah (4.8 kWh) |
— |
1 |
| Max. Battery Modules in Parallel |
4 |
2 |
| Recommended Battery Bank Capacity |
2.6 – 5.1 kWh |
7.2 – 9.6 kWh |
| COMMUNICATION, ENVIRONMENT & COMPLIANCE |
| Communication Interface |
RS232 / GPRS / Wi-Fi |
|
| Remote Monitoring (Wi-Fi / app) |
Yes — Wi-Fi or GPRS dongle, iOS and Android |
Yes — Wi-Fi or GPRS dongle, iOS and Android
|
| Operating Temperature |
−10 °C to +50 °C |
−10 °C to +50 °C |
| Relative Humidity |
5 % to 95 %, non-condensing |
5 % to 95 %, non-condensing
|
| Cooling |
Forced air |
Forced air |
| Compliance / Safety Mark |
CE |
CE |
